All models feature an innovative CPU and the new 2295 Hz printhead for outstanding productivity on texts and graphics alike. The printer produces 291 pages per hour on the ECMА Test, more than any other model in its product class.
Attention to printing quality is combined with superior productivity: PR9+ uses a new-generation ink ribbon able to print up to 10 million characters. The 24-pin printhead (0.25 mm diameter) is designed to service the entire machine life (at least 5 years) and manage a daily workload of more than 300 transactions at competitive speeds.
The standard model provides RS 232, IEEE 1284 parallel and USB 2.0 interfaces. Options include: second USB port, second serial port and Ethernet interface.
Features & Benefits
- One of the smallest and quietest in its product class
- Extremely easy to use
- Management of all bank forms
- Ultra-fast alignment for improved performance
- Dual-side colour scanning (optional)
- Magnetic-stripe reading-writing, MICR codeline reading
- Outstanding graphics management
- Superior printing speeds: up to 660 character/sec in VHSD
- New ink ribbon prints up to 10 million characters
Technical Specifications
| Technology |
24-pin dot matrik |
| Resolution |
240 x 300 dp |
| Fonts |
OCR A-B ROMAN Sans Serif, Italic, Courier |
| Pitch |
10, 12, 15, 16.6, 171, 20 срі |
| Printing speed at 10 cpi |
VHSD: 660 cps - HSD: 520 cps
Draft: 400 cps -NLQ: 200 cps
LQ: 135 cps - BIM: 2000 dps |
| Line length |
238.76 mm (94 columns at 10 cpi) |
| Line spacing |
1/5", 1/6", n/216", n/240" |
| Copies |
Original + 6 copies |
| Interfaces |
Standard, RS232 serial,
IEEE 1284 parallel and USB 2.0
Optional: second USB port, second serial port and Ethernet interface |
| Emulations |
Olivetti Standard, IBM PP & X24
Optional: 1BM 4722/9068, IBM PP & X24, WINCOR 4915, EPSON LQ 2550, UNBEYS EFP series |
| Noise level |
<52 dBA |
| Document Handling |
- Feed width: 245 mm
- Max thickness: 4 mm
- Completely flat paper feed
- Automatic insertion with autoborder
- Automatic document-thickness monitoring
|
| Power consumption |
Min. 25 W - Max. 85 W (printing) |
| Ribbon cartridge |
10 million characters |
| Voltage |
230V / 50Hz - 115V / 60Hz |
| Certifications & Regulatory |
CE, TÜV NRTL, FCC class A verified |
| Dimensions (WxDxH) |
384 x 296 x 204mm (15.12" x 11.65" x 8.03") |
| Weight |
10.5 Kg |
| Input Buffer |
32~256KB |
| Options |
MICR reader (CMC7, EI3B)
Double Color printing (red & black) |
